RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

Brand Name : Xrido

Model Number : Customizable

Certification : CE ISO TUV

Payment Terms : Negotiable

Delivery Time : 2-30 Working Days

place of origin : Henan, China

type : Refuse Collector

warranty : 1 Year

material : Export Wooden Packing

machinery test report : Provided

video outgoing-inspection : Provided

core components : Pressure vessel, motor, Bearing, Gear, PLC, Pump, Engine

weight (kg) : 800

Power : Custom

Product name : Refuse Derived Fuel RDF Briquette Press Machine

Application : Recycling and Utilization of Waste

Suitable material : Hard Wood Briquette

After Warranty Service : Field Maintenance

Advantage : Easy Operation High Efficiency

Briquette size : 8-75mm

Usage : Make Fuel Briquettes

Production Capacity : 100%

Voltage : Country Voltage

Contact Now

RDF Making Machine Garbage Briquette Compression Making Machine Biomass Roller Press Rdf Briquetting Machine SRF Briquetting Machine
Products Description
RDF (Refuse Derived Fuel) briquetting machine is a special equipment that compresses pretreated urban solid waste (such as combustibles such as plastics, paper, and fabrics) into high-density fuel blocks after crushing, sorting, drying, etc. Its core function is to convert loose flocculent RDF raw materials (cRDF) into granular or block (dRDF) with a density of 0.8-1.2 tons/cubic meter, significantly improving transportation efficiency and combustion performance. This equipment is usually integrated at the end of the RDF production line and is formed by hydraulic or mechanical pressure. It is a key equipment for waste energy utilization.

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

What kind of equipment is needed to convert solid waste into high calorific value alternative fuel? XRIDO Group is a solid waste pretreatment equipment provider with more than 10 years of experience in the solid waste pretreatment equipment industry. Focusing on the three major mixed domestic waste/other waste pretreatment goals of "recyclable sorting", "organic matter extraction", and "combustible preparation of RDF/SRF", it provides a complete set of mature and reliable alternative fuel (RDF/SRF) preparation systems and equipment. At present, there are project cases in domestic waste transfer stations, renewable resource utilization centers, and cement manufacturing industries in various regions.

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

Advantages of RDF briquetting machine

Resource benefits: Convert low calorific value garbage into standard fuel (calorific value 16-25MJ/kg), replace fossil energy such as coal, and reduce landfill volume by more than 30%.
Environmental friendliness: No binder is required during the compression process, sulfur oxide emissions during combustion are 50% lower than coal, and ash can be used as raw materials for building materials.
Economic efficiency: The volume of fuel is reduced by 3-5 times after molding, reducing transportation and storage costs, and can be adapted to various industrial facilities such as cement kilns and power generation boilers.
Technical adaptability: The modular design can handle a variety of raw materials such as mixed garbage and industrial waste, and the intelligent control system can achieve precise adjustment of moisture content (≤15%) and density.

Product Application

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

Decoration waste RDF/SRF alternative fuel preparation system. Through a variety of refined preparation processes such as crushing, screening, magnetic separation, and air separation, the sand, soil, metal and other debris in the decoration waste are separated, and finally the light combustibles are prepared into high calorific value RDF/SRF alternative fuels.
Model XRD600 XRD800
Capacity(t/h) 2.5-3 4-4.5
Motor power(kw) 180(90*2) 220(110*2)
Ring mold size(mm) ∅608 ∅768
Press roller quantity(pcs) 2
Transmission method Asynchronous motor
V-belt + gear		 Water-cooled synchronous motor
Timing belt + gear
Feeding type Horizontal screw + forced feeding
Machine size(m) 3.2*2.2*2.1 3.2*2.3*2.1
Weight(kgs) 8480 13900

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

Providing one-stop Solution

The company's main products include double-axis shredders, metal crushers, solid waste disposal equipment and renewable resource equipment to meet the needs of different customers. By providing a one-stop solution, XRIDO Group can helps customers solve various solid waste treatment problems.

Waste to Biomass/RDF/SRF/TDF Briquette System:

The solid waste disposal system can be customized according to the actual materials.

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine
MSW to RDF briquette Plant Industrial Waste to RDF briquette Plant

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine
Biomass pellet/briquette Plant Waste Tire Disposal System
Case:

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine

RDF Making Machine Garbage Briquette Compression Making Biomass Roller Press Rdf Briquetting Machine
