Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Brand Name : Xrido

Model Number : Customizable

Certification : CE ISO TUV

MOQ : 1 set

Payment Terms : Negotiable

Delivery Time : 2-30 Working Days

place of origin : Henan, China

video outgoing-inspection : Provided

machinery test report : Provided

core components : PLC, Engine, Bearing

brand name : Xrido

warranty : 1 Year

material / metal processed : Stainless Steel, Brass / Copper, Alloy, Carbon Steel, Aluminum

key selling points : Automatic

Name : Waste Palstic Crushing

Keyword : Double Shaft Scrap Metal Recycling

Final product : 1-10 Cm

Advantage : High Efficiency Low Energy Consumption

Type : Environment-friendly

Material Processed : PE Film PP Woven Bags

After-sales Service Provided : Service Machinery Overseas

Contact Now

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Products Description

Glass plate crusher is a mechanical equipment specially used for crushing hard glass materials such as flat glass and industrial glass. It mainly crushes large glass plates into particles of controllable size through mechanical force (such as impact, extrusion, shearing, etc.).

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Working principle of glass plate crusher ‌
Compound crusher achieves fine crushing of brittle materials through impact force
Double-tooth roller crusher uses relatively rotating tooth rollers to squeeze and shear glass
Shredder cuts materials through the interaction of moving knife and fixed knife

Applicable scenarios of glass plate crusher ‌
Recycling of architectural glass, automotive glass, and photovoltaic panel glass
Crushing of industrial glass waste (such as beer bottles and glass cans)
Glass sand preparation (crushing waste glass into sand-like particles)

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

model
size(mm)
Shredder room(mm)
Blads(mm)
motor(k)
weight(kg)
XD-600
2800×1300×1850
600×480
200
11×2
2200
XD-800
3000×1300×1850
800×480
200
15×2
2500
XD-1000
3300×1900×2200
1000×690
300
22×2
5200
XD-1200
3600×2000×2200
1200×690
300
30×2
6400
XD-1500
4180×2100×2400
1500×850
550
55×2
9000
XD-1800
5800×2400×3300
1800×1206
550
75×2
13600
XD-2000
6400×2700×3500
2000×1490
600
90×2
20100
XD-2500
7500×3200×3800
2500×1800
600
110×2
25000
Notes:
1. The number of blade claws, diameter, and thickness can be customized according to the type of material and the size of the discharge.
2. The output of the equipment will be different depending on the type of material and the size of the discharge.
3. More information please contact us, we can custom the product on your request.

Waste shredders have significant technical advantages in the field of waste treatment, which are mainly reflected in the following aspects:

High-efficiency crushing capacity:
Adopting a double-axis staggered shearing design and equipped with high-strength alloy cutters, it can effectively handle various complex materials (such as plastics, metals, wood, rubber, etc.), and the crushing efficiency is more than 30% higher than that of single-axis equipment, and the output particle size is uniform (usually controlled at 10-100mm adjustable).

Strong adaptability:
By replacing different cutters (such as hook knives, square knives, round knives, etc.), customized crushing can be performed for wastes of different hardness and toughness, which is suitable for electronic waste, large solid waste, waste tires and other scenarios.

Low energy consumption and high stability:
Adopting a hydraulic or motor direct drive system, combined with intelligent overload protection, the energy consumption is reduced by 15%-20% compared with traditional crushers, and the continuous operation failure rate is less than 1%.

Environmental protection and resource utilization advantages:
The volume of the crushed material is reduced by 50%-80%, which greatly reduces the transportation and landfill costs. At the same time, it provides ideal raw materials for subsequent sorting, smelting, and recycling, and promotes the development of a circular economy.

Intelligent development:
The new equipment integrates PLC control system and sensor technology to achieve automatic lubrication, fault alarm and remote monitoring, and promote the upgrading of waste treatment to automation and intelligence.

At present, the double-axis shredder has become the core equipment for solid waste treatment, playing a key role in garbage recycling, renewable resource processing and other fields.

Details Images

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Main Application:
1. All kinds of hollow containers: plastic beverage cans, plastic barrels, drums, packing box, packing barrel
2. Waste appliances:TV, washing machine, refrigerator shell, printer, keyboard, waster Microwave oven,waster computer,waster mouse,Circuit board.
3.Pipe: large pipe, pipe fittings, PE pipe,PVC tube.
4. Waste template: wooden pallets, plastic pallets, forklift pallets,Used furniture.
5. Scrap tires: car tires, truck tires, engineering tires.
6. Scrap metal: car shell, aluminum alloy, scrap aluminum castings, engine shell
7. Garbage: Food waste,animal carcass, medical waste, garden garbage,Fruit trash,Vegetable trash,glass.
8.Rubber head material, paper mill rope.

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Providing one-stop Solution

The company's main products include double-axis shredders, metal crushers, solid waste disposal equipment and renewable resource equipment to meet the needs of different customers. By providing a one-stop solution, XRIDO Group can helps customers solve various solid waste treatment problems.

Waste crushing, sorting and recycling system:

The solid waste disposal system can be customized according to the actual materials.

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Waste Metal Recycling System Electronic Waste Recycling System

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Solid Waste Disposal System RDF Briquetting System


FINAL PRODUCT

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant


Customer Site

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant

Glass Plate Crusher Waste Glass Shredder Waste Shredder Machine Solid Waste Shredder Industrial Waste Shredder Solid Waste Dispose Plant
